VOLTAGE SENSITIVE RELAY 125A CONT CUT-IN 13.3V CUT-OUT 12.8V

VOLTAGE SENSITIVE RELAY 125A CONT CUT-IN 13.3v CUT-OUT 12.8V

FEATURES

Ideal for dual battery systems or to switch high current appliances.
Suits ATV, boats, RV’s, caravans and trucks.
VSR allows 2 batteries to be charged at the same time, once start battery reaches cut-in voltage.
No voltage drops compared to battery isolator diodes (0.6V).
Robust glass fibre reinforced nylon enclosure.
M6 stud size.
Built-in LED indication (ON when VSR engages).
Rated protection: IP67.
Surface or panel mount options provide flexibility when installing.
Load rating @12V:
125A maximum continuous.
140A intermittent.
Cut-in: 13.3V / Cut out: 12.8V.
Power consumption:
0mA (storage).
10mA (standby).
330mA (engage).
Ignition protection.
Mounting hardware included.
CE certified.
