Description
FEATURES
Utilising magnetic field to control the reed on-off switch, the sender features a long service life and protection against vibration.
SAE Standard: 5 mounting holes.
316G stainless steel main body.
Rubber gasket provides a liquid tight seal.
IP67 rated.
Operating temperature: -40 Degree Celsius – +85 Degree Celsius.
300mm tinned wire with a PVC material cover.
Stainless steel screws included.
33mm float cut out.
SPECIFICATIONS
Part No. 40225
Length 225mm
Mount Style 5 Hole
Mount Flange Dia. 69mm
OHMS 240-33
Note Special sizes available to order. Length is measured from underside of the flange to the base of the shaft.
